GB 15CrMo | DIN 16CrMo44/1.7337 Engineering steel

Port: Hu nan

16CrMo44 engineering steel, 16CrMo44 alloy tool steel, 16CrMo44 alloy steel, 16CrMo44 alloy structural steel, 1.7337 engineering steel, 15CrMo engineering steel

Alloy Structural Steel, Alloy Tool Steel, Carbon Structural Steel, Carbon Tool Steel, Bearing Steel, Spring Steel ,Stainless Steel, Refractory Steel, Roll Steel, Pinion Steel. Additionally, the company also has the capacity to forge round steel, steel flat, square steel, module, shaft and roller

E-mail:export@qilucs.com

  • Quick Details

    1: 16CrMo44 steel introduction

        16CrMo44 is a special steel with good process and welding properties. The steel has good process and welding properties, and high rupture strength at 500~550℃. When the temperature exceeds 550℃, the oxidation resistance becomes worse and the creep strength decreases significantly. The thermal strength and strength of the steel will decrease when it is at 500~550℃ for a long time.



    2: 16CrMo44 steel equivalent

    Country China Japan Germany USA
    Standard GB/T 3077 JIS

    DIN (W-Nr.)

    AISI/ASTM

    Grade 15CrMo
    16CrMo44


    3: 16CrMo44 steel chemical composition

    Grade C Si Mn P S Cr Mo
    16CrMo44 0.13-0.20 0.15-0.35 0.50-0.80 0.025 0.035
    0.90-1.20 0.40-0.50
    15CrMo
    0.12-0.18 0.17-0.37 0.40-0.70 0.035 0.035 0.80-1.10 0.40-0.55


    4: 16CrMo44 steel mechanical properties

        The mechanical properties mainly include tensile strength, yield strength, elongation, area or reduction, hardness, impact value, non-metalic inclusion etc. Different heat treatment, the mechanical properties will be different, such as normalized, tempered, QT. If you want to know the properties, kindly contact the salesman.


    5: 16CrMo44 steel overviews

    Size Round Dia 6-1200mm
    Plate/Flat/Block Thickness
    6mm-500mm
    Width
    20mm-1000mm
    Heat treatment Normalized ; Annealed ; Quenched ; Tempered
    Surface condition Black; Peeled; Polished; Machined; Grinded; Turned; Milled
    Delivery condition Forged; Hot rolled; Cold drawn
    Test Tensile strength, Yield strength, elongation, area of reduction, impact value, hardness, grain size, ultrasonic test, US inspection, magnetic particle testing, etc.
    Payment terms T/T;L/C;/Money gram/ Paypal
    Trade terms FOB; CIF; C&F; etc..
    Delivery time 30-45 days
    Application  16CrMo44 is used to manufacture 510℃ high and medium pressure steam conduit, header, superheater and forgings with 550℃ wall temperature.


    6: Heat Treatment

          Heat treatment temperatures, rate of heating, cooling and soaking times will vary due to factors such as the shape and size of each component. Other considerations during the heat treatment process include the type of furnace, the quenching medium and work piece transfer facilities. Please consult a heat treatment specialist for full guidance on heat treatment.


    7: Delivery condition

        For hot forged  bar, usually the delivery condition is hot forged, annealed/QT, rough turned/Black surface.
        For hot rolled bar, usually the delivery condition is hot rolled, annealed/QT, Black surface.
        For hot forged block, usually the delivery condition is hot forged, annealed/QT, milled surface/Black surface
        For hot rolled plate, usually the delivery condition is hot rolled, annealed/QT, black surface.
        For cold drawn bar, usually the delivery condition is cold drawn, annealed/QT, peeled/black surface
