DIN 110WCrV5/1.2519 Hot Work Tool Steel

Port: Hu nan

110WCrV5 hot work tool steel, 110WCrV5 tool steel, 110WCrV5 alloy tool steel, 110WCrV5 alloy steel, 1.2519 hot work tool steel

Alloy Structural Steel, Alloy Tool Steel, Carbon Structural Steel, Carbon Tool Steel, Bearing Steel, Spring Steel ,Stainless Steel, Refractory Steel, Roll Steel, Pinion Steel. Additionally, the company also has the capacity to forge round steel, steel flat, square steel, module, shaft and roller

E-mail:export@qilucs.com

  • Quick Details

    1: 110WCrV5 steel introduction

            110WCrV5 is a German Cold work tool alloy steel material grade. it is shock resisting steel. it belong to DIN 17350 standard.


    2: 110WCrV5 Steel equivalent

    Country China Japan Germany USA UK
    Standard GB JIS DIN 17350 ASTM BS
    Grade

    110WCrV5


    3: 110WCrV5 steel chemical composition

    Grade C Mn Cr Si V W
    110WCrV5
    1.05-0.15 0.20-0.40 1.10-1.30 0.15-0.30 0.15-0.25
    1.20-1.40


    4: 110WCrV5 steel mechanical properties

        The mechanical properties mainly include tensile strength, yield strength, elongation, area or reduction, hardness, impact value, non-metalic inclusion etc. Different heat treatment, the mechanical properties will be different, such as normalized, tempered, QT. If you want to know the properties, kindly contact the salesman.


    5: 110WCrV5 steel overviews

    Size Round Dia 6-1200mm
    Plate/Flat/Block Thickness
    6mm-500mm
    Width
    20mm-1000mm
    Process EAF+LF+VD+Forged+Heat treatment(optional)
    Heat treatment Normalized ; Annealed ; Quenched ; Tempered
    Surface condition Black; Peeled; Polished; Machined; Grinded; Turned; Milled
    Delivery condition Forged; Hot rolled; Cold drawn
    Test Tensile strength, Yield strength, elongation, area of reduction, impact value, hardness, grain size, ultrasonic test, US inspection, magnetic particle testing, etc.
    Payment terms T/T;L/C;/Money gram/ Paypal
    Trade terms FOB; CIF; C&F; etc..
    Packing  Standard packages or as per customers request.
    Delivery time 30-45 days
    Application  110WCrV5 is used for planer blades, taper paper, paperboard and tobacco paperboard and tobacco.


    6: Delivery condition

        For hot forged or hot rolled bar, usually the delivery condition is hot forged or rolled, annealed, rough turned.
        For hot forged plate, usually the delivery condition is hot forged, annealed, milled surface.

        For hot rolled plate, usually the delivery condition is hot rolled, annealed, black surface.
