ASTM A8 Cold Work Tool Steel

Port: Hu nan

A8 alloy steel, A8 tool steel

Alloy Structural Steel, Alloy Tool Steel, Carbon Structural Steel, Carbon Tool Steel, Bearing Steel, Spring Steel ,Stainless Steel, Refractory Steel, Roll Steel, Pinion Steel. Additionally, the company also has the capacity to forge round steel, steel flat, square steel, module, shaft and roller


  • Quick Details

    1: AISI A8 steel introduction

        AISI A8 is high strength, high chromium steel engineering plastic, forging special steel, is also a kind of oil-cooled, air-cooled hardened die steel. It is suitable for high cut-off cutting and forming processing, with high wear resistance and high toughness of multi-use high alloy die steel. AISI A8 has high haedness, excellent corrosion resistance, high temperature characteristics, and common hardness range is 52-58 HRC.

    2: AISI A8 Steel equivalent

    Country China Japan Germany USA UK
    Standard GB/T 1299 JIS G4404 DIN EN ISO4957 ASTM A681 BS 4659
    Grade / / / A8 /

    3: AISI A8 steel chemical composition

    Grade C Mn P S Si Cr V Mo
    A8 0.50 0.60 0.20 0.50 0.03 0.03 0.75 1.10 4.75 5.50 1.00 1.50 1.50

    4: AISI A8 steel mechanical properties

        The mechanical properties mainly include tensile strength, yield strength, elongation, area or reduction, hardness, impact value, non-metalic inclusion etc. Different heat treatment, the mechanical properties will be different, such as normalized, tempered, QT. If you want to know the properties, kindly contact the salesman.

    5: AISI A8 steel overviews

    Size Round Dia 6-1200mm
    Plate/Flat/Block Thickness
    Process EAF+LF+VD+Forged+Heat treatment(optional)
    Heat treatment Normalized ; Annealed ; Quenched ; Tempered
    Surface condition Black; Peeled; Polished; Machined; Grinded; Turned; Milled
    Delivery condition Forged; Hot rolled; Cold drawn
    Test Tensile strength, Yield strength, elongation, area of reduction, impact value, hardness, grain size, ultrasonic test, US inspection, magnetic particle testing, etc.
    Payment terms T/T;L/C;/Money gram/ Paypal
    Trade terms FOB; CIF; C&F; etc..
    Packing Standard Packages, or as Customers Request
    Delivery time 30-45 days
    Application  AISI A8 is used for precision die, edge cutting die, deep drawing die, cold forging die, pendulum rolling die, rolling die, cold extrusion die with complex shape and pipe drawing die.

    6. AISI A8 Tool Steel Heat Treatment

    Tempering of A8 steels is performed at 148-315°C (300-600°F), Double tempering is recommended for tempering temperatures of 900°F and higher. Soak well at the selected temperature and soak for at least one hour per 25mm of total thickness.

    7: Delivery condition
        For hot forged or hot rolled bar, usually the delivery condition is hot forged or rolled, annealed, rough turned.
        For hot forged plate, usually the delivery condition is hot forged, annealed, milled surface.

        For hot rolled plate, usually the delivery condition is hot rolled, annealed, black surface.
